PSC1-E-37-14DI-4DO-2RO-RIO Schmersal Safety Accessories
Part#:PSC1-E-37-14DI-4DO-2RO-RIO
Manufacturer:Schmersal
Category:Safety Accessories
Alt. Part#:103008459
Product Lifecycle:Active
Get a quick Quote!
PSC1-E-37-14DI-4DO-2RO-RIO Schmersal - Safety controllers; PROTECT PSC1; Decentral expansion with 14 digital inputs; 4 safe 2 A pp-switching semiconductor outputs, switchable to 2 safe pn-switching outputs; 14 safe inputs on the base module; 2 Signalling outputs; 2 safety relay contacts
About the manufacturer: Schmersal is one of the manufacturers that offers Safety Accessories that you can order at Applied Automation site. Schmersal produces a wide range of high-quality switchgears specifically engineered to protect machinery and facilities in industrial automation and the elevator industry.
Check out the PSC1-E-37-14DI-4DO-2RO-RIO Schmersal price in the box on the right side or send a quick quote.
Product Details
- Interfering radiation DIN EN 61000-6-4
- EMC rating DIN EN 61000-6-7, DIN EN 61326-3, DIN EN 61000-6-2
- Electromagnetic compatibility DIN EN 62061, DIN EN 61800-3
- Current, Utilisation category DC13 2 A
- Voltage, Utilisation category DC13 24 VDC
- Current, Utilisation category AC-15 2 A
- Voltage, Utilisation category AC15 230 VAC
- Versions short-circuit proof, p-type (Q2 und Q3)
- Operating voltage, maximum 28.8 VDC
- Operating voltage, minimum 20.4 VDC
- Rated operating current (safety outputs) 2,000 mA
- Overvoltage category III
- Designation, Communication interface RJ45
- Zulässige Aufstellhöhe über NN, maximum 2,000 m
- Note (Relative humidity) non-condensing
- Degree of pollution to IEC/EN 60664-1 2
- Relative humidity, maximum 85 %
- Storage and transport temperature, maximum +70 °C
- Relative humidity, minimum 5 %
- Storage and transport temperature, minimum -25 °C
- Ambient temperature, maximum +50 °C
- Ambient temperature, minimum +0 °C
- Degree of protection IP20
- Depth 115 mm
- Height 100 mm
- Wire cross-section, maximum 12 AWG
- Width 67.5 mm
- Wire cross-section, minimum 24 AWG
- Cable section, maximum 2.5 mm²
- Cable section, minimum 0.2 mm²
- Mounting can be clipped into standard rail
- Number of signalling outputs 2
- Master-Slave-Kommunikation Yes
- Number of fail-safe digital outputs 4
- Gross weight 554.7 g
- Number of digital fail-safe inputs 14
- Number of relay outputs (1-channel) 2
- Number of pulse outputs (test pulse output) 2
- Terminal (mechanical) Removable screw terminals
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
PSC1-E-37-14DI-4DO-2RO-RIO Description
PSC1-E-37-14DI-4DO-2RO-RIO Schmersal - Safety controllers; PROTECT PSC1; Decentral expansion with 14 digital inputs; 4 safe 2 A pp-switching semiconductor outputs, switchable to 2 safe pn-switching outputs; 14 safe inputs on the base module; 2 Signalling outputs; 2 safety relay contacts
Related documents PSC1-E-37-14DI-4DO-2RO-RIO Specs
