NMEFRT Schmersal Indicator Lights

Product Details

• Ambient temperature, maximum
  +80 °C
• Degree of protection
  IP67, IP69K
• Spacing
  50 x 50 mm
• Ambient temperature, minimum
  -25 °C
• Diameter hole, with tolerance indication
  22.3 + 0.4 mm
• Thickness of the front panel, maximum
  6 mm
• Thickness, of the front panel, minimum
  1.5 mm
• Diameter hole
  22.3 mm
• Diameter of the front ring
  44.5 mm
• Diameter of the dome
  26 mm
• Diameter total
  44.5 mm
• Tightening torque of the screw
  0.6 Nm
• Height of the dome
  2 mm
• Integral System Diagnostics, general
  Yes
• Mounting
  Mounting flange ELM
• Mounting flange
  Yes
• Fully insulated
  Yes
• Gross weight
  50 g
• Illuminable
  Yes
• Standards
  EN 60947-5-1, IEC/EN 60947-1
Sealing type
Membrane, Lip gaskets, Form seals
Colour of the front ring
Silver
Material of the dome
PA (12)
Design
Round, Flat dome
Versions
LED - Indicator light - Front plate mounting
Material of the front ring
ABS, chrome-plated
Installation conditions (mechanical)
arbitrarily
Colour of the dome
Red
