NDTP30GR/GB Schmersal Pushbuttons
Part#:NDTP30GR/GB
Manufacturer:Schmersal
Alt. Part#:103009112
Product Lifecycle:Active
Get a quick Quote!
NDTP30GR/GB Schmersal - Mushroom Button from N Series (IP69K)
About the manufacturer: Schmersal is one of the manufacturers that offers Pushbuttons that you can order at Applied Automation site. Schmersal produces a wide range of high-quality switchgears specifically engineered to protect machinery and facilities in industrial automation and the elevator industry.
Check out the NDTP30GR/GB Schmersal price in the box on the right side or send a quick quote.
Product Details
- Ambient temperature, maximum +80 °C
- Ambient temperature, minimum -25 °C
- Thickness of the front panel, maximum 6 mm
- Diameter hole, with tolerance indication 22.3 + 0.4 mm
- Degree of protection IP67, IP69K
- Spacing 50 x 50 mm
- Thickness, of the front panel, minimum 1.5 mm
- diameters for the actuating heads 30 mm
- Mounting Mounting flange EFM
- Diameter hole 22.3 mm
- Gross weight 36 g
- Actuating stroke 5 mm
- Height 20 mm
- Fully insulated Yes
- Tightening torque of the screw 0.6 Nm
- Colour of the bellows Black
- Mounting flange Yes
- Material of the operators Plastic
- Probing possible Yes
- Material of the bellows Silicone
- Sealing type Membrane, Lip gaskets
- Design Round
- Colour of the operating element Yellow
- Colour of the front ring Silver
- Versions round, Mushroom button
- Material of the front ring ABS, chrome-plated
- Standards EN 60947-5-1, IEC/EN 60947-1
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
NDTP30GR/GB Description
NDTP30GR/GB Schmersal - Mushroom Button from N Series (IP69K)
Related documents NDTP30GR/GB Specs
