BNS 260-02Z-L Schmersal Electronic Components

Product Details

• Switching frequency, maximum
  5 Hz
• Switching capacity, maximum
  10 VA
• Resistance to vibrations to EN 60068-2-6
  10 … 55 Hz, amplitude 1 mm
• Switching current, maximum
  0.4 A
• Switching voltage, maximum
  75 VDC
• Restistance to shock
  30 g / 11 ms
• Voltage type
  DC (direct current)
• Storage and transport temperature, minimum
  -25 °C
• Storage and transport temperature, maximum
  +70 °C
• Ambient temperature, maximum
  +70 °C
• Degree of protection
  IP67
• Ambient temperature, minimum
  -25 °C
• Length of sensor
  13 mm
• Material of the Cable mantle
  PVC
• Height of sensor
  36 mm
• Width of sensor
  26 mm
• Actuating element
  Magnet
• Length of cable
  1 m
• Direction of motion
  Head-on to the active surface
• Terminal Connector
  Cable
Door hinge
Left
Notice (Switch distance Sn)
Axial misalignment, a horizontal and vertical misalignment of the safety sensor and the actuator are tolerated. The possible misalignment depends on the distance of the active surfaces of the sensor and the actuator. The sensor remains active within the t
Ensured switch distance ON Sao
5 mm
Ensured switch distance OFF Sar
15 mm
Wire cross-section
0.25 mm2
Coding level according to ISO 14119
Low
Number of safety contacts
2
Standards
IEC 60947-5-3, BG-GS-ET-14
Enclosure material
Glass-fibre, reinforced thermoplastic
Installation conditions (mechanical)
quasi-flush
Gross weight
55 g
Active principle
Magnetic drive
Number of openers
2
Number of cable wires
4
