AZM 415-33ZPDK 230VAC Schmersal Safety Switch Interlocks
Part#:AZM 415-33ZPDK 230VAC
Alt. Part#:101117713
Manufacturer:Schmersal
Category:Safety Switch Interlocks
Product Lifecycle:Active
Product description
Solenoid interlocks; Ball latch for each door, individually adjustable up to 400 N; 3 switches in one enclosure; Spring-loaded actuators; for double doors; 141 mm x 125 mm x 46,5 mm; Metal enclosure; Interlock with protection against incorrect locking.; R
Product Details
- Utilisation category DC-13 1 A
- Switching element NO contact, NC contact
- Switching principle Creep circuit element
- Rated control voltage 230 VAC
- Electrical power consumption, maximum 10 W
- Ambient temperature, maximum +50 °C
- Rated impulse withstand voltage Uimp 4 kV
- Utilisation category AC-15 4 A
- Thermal test current 6 A
- Rated insulation voltage Ui 250 V
- Ambient temperature, minimum -25 °C
- Degree of protection IP67
- Height of sensor 125 mm
- Width of sensor 141 mm
- Length of sensor 46.5 mm
- Note (Cable section) All indications about the cable section are including the conductor ferrules.
- Cable section, maximum 2 x 2.5 mm²
- Terminal Connector Screw connection
- Cable section, minimum 2 x 0.75 mm²
- Actuating speed, maximum 0.2 m/s
- positive break travel 4.5 mm
- Latching force, maximum 400 N
- Positive break force, minimum 15 N
- Number of guard doors 2
- Note (Clamping force) each guard
- Clamping force in accordance with ISO14119 Fzh 2,500 N
- Mechanical life, minimum 1,000,000 Operations
- Latching force, minimum 150 N
- Standards EN 60947-5-1, BG-GS-ET-19
- Number of safety contacts 3
- Enclosure material Aluminium
- Material of the contacts, electrical Silver
- Gross weight 1,515 g
- Enclosure coating material painted
- Number of auxiliary contacts 3
- Power to unlock Yes
- Number of actuating directions 1
- Active principle electromechanical
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
