AZM 415-11/02ZPKFE 24VAC/DC Schmersal Safety Switch Interlocks

Product Details

• Switching element
  NO contact, NC contact
• Switching principle
  Creep circuit element
• Electrical power consumption, maximum
  10 W
• Utilisation category DC-13
  1 A
• Positive break force, minimum
  15 N
• Terminal Connector
  Screw connection
• Latching force, maximum
  400 N
• Rated impulse withstand voltage Uimp
  4 kV
• Utilisation category AC-15
  230 VAC
• Rated insulation voltage Ui
  250 V
• Thermal test current
  6 A
• Rated control voltage
  24 VAC/DC
• Ambient temperature, minimum
  -25 °C
• Height of sensor
  100 mm
• Width of sensor
  130 mm
• Degree of protection
  IP67
• Length of sensor
  71.5 mm
• Cable section, minimum
  2 x 0.75 mm²
• Cable section, maximum
  2 x 2.5 mm²
• Actuating speed, maximum
  0.2 m/s
positive break travel
5 mm
Clamping force in accordance with ISO14119 Fzh
3,500 N
Mechanical life, minimum
1,000,000 Operations
Number of guard doors
1
Number of safety contacts
3
Active principle
electromechanical
Manual release
Yes
Gross weight
1 g
Number of actuating directions
1
Power to unlock
Yes
Material of the contacts, electrical
Silver
Enclosure coating material
painted
Enclosure material
Aluminium
Standards
EN 60947-5-1, BG-GS-ET-19
Ambient temperature, maximum
+50 °C
Note (Cable section)
All indications about the cable section are including the conductor ferrules.
Latching force, minimum
150 N
Number of auxiliary contacts
1
