86326 Murr Elektronik General Purpose Transformers

Product Details

• Weight
  4300 g
• Series
  Transformators/Power Supplies
• Product article number of manufacturer
  86326
• Frequency
  50...60 Hz
• Mounting method
  Key-hole mounting
• Input current
  1.52 A (230 V AC); 0.88 A (400 V AC)
• Short-circuit current
  28 A (230 V AC); 16.1 A (400 V AC)
• Inrush current
  17.5 A (230 V AC); 10.1 A (400 V AC)
• Input voltage
  230/400 V AC
• Test isolation voltage
  4 kV (prim./sec.)
• Temperature range
  -20...+40 °C (storage temperature -40...+80 °C)
• Output rating
  320 VA
• Dimensions H×W×D
  92×120×122.4 mm
• Drill hole Ø
  5.8×10 mm
• Output voltage
  24 V AC (SELV)
• Fixing centers a×b×c
  74.4×90×5.8 mm
• Standards
  EN 61558-1, EN 61558-2-6, EN 62041 category 0
