85704 Murr Elektronik AC/DC Power Supplies

Product Details

• Weight
  1340 g
• Series
  Transformators/Power Supplies
• Product article number of manufacturer
  85704
• Frequency
  50...60 Hz
• Input fuse (internal)
  10 A (T)
• Inrush current after 1 ms
  max. 23 A (230 V AC)
• Power factor
  0.96 (230 V AC)
• Input current
  5.2 A (100 V AC); 2.2 A (240 V AC)
• Parallel usage/serial usage
  max. 5 units/max. 2 units
• Spikes
  max. 200 mV ss/pp
• Efficiency
  91.7% (110 V AC); 94.1% (230 V AC)
• Input voltage
  90...265 V AC/90...250 V DC
• Ripple
  max. 50 mV eff/rms
• Mains failure bridging time
  min. 30 ms (100 V AC); 20 A (24 V DC)
• Relative humidity
  5...95%, no condensation
• Temperature range
  -40...+60 °C, ...+70 °C derating (storage temperature -40...+80 °C)
• Unit protection
  short-circuit and overload protected
• Output current
  20 A
• LED display
  LED (green): OK; LED (red): overload, overheating or short-circuit
• Output voltage
  24 V DC (SELV), ±1%; 24...28 V adjustable
Mounting method
4 hole screw mounting
Dimensions H×W×D
123×85×138 mm
Connection
Push-In spring clamp terminals
Power Boost
Iout N × 150% (min. 4 s)
Protection
IP20
Standards
IEC 61010-2-201, EN 61204-3, EN 55011 B, EN 61000-3-2, SEMI F47

Related documents 85704 Specs
