85677 Murr Elektronik AC/DC Power Supplies

Product Details

• Weight
  1900 g
• Series
  Transformators/Power Supplies
• Product article number of manufacturer
  85677
• Power factor
  0.88 (230 V AC)
• No. of channels
  2× MICO (Over current protection device)
• Inrush current after 1 ms
  max. 5.9 A  (230 V AC)
• Input fuse (internal)
  6.3 A (T)
• Input voltage
  90...265 V AC/90...265 V DC
• Frequency
  50...60 Hz
• Input current
  1.2 A (240 V AC)
• Parallel usage/serial usage
  no
• Output current
  max. 8 A (per channel), max. 10 A (total)
• Mains failure bridging time
  min. 20 ms (230 V AC)
• Ripple
  max. 10 mV eff/rms
• Connection
  7/8" (female), 4-pole
• Unit protection
  Short-circuit, overload and temperature
• Spikes
  max. 150 mV ss/pp
• LED display
  LED (green): OK; LED (red): overload, overheating or short-circuit
• Output voltage
  24 V DC (SELV), ±1%; 24...28 V adjustable
• Dimensions H×W×D
  216×110×53 mm
Efficiency
91.6% (115 V AC); 92.8% (230 V AC)
Mounting method
6 hole screw mounting
Protection
IP67
MTBF
430 000 h
Temperature range
-25...+50 °C, ...+80 °C derating (storage temperature -25...+85 °C)
Relative humidity
4...100%
Standards
IEC 61010-2-201, EN 61204-3, EN 55022 B, EN 61000-3-2
