85414 Murr Elektronik UPS (DC)

Product Details

• Weight
  640 g
• Series
  Transformators/Power Supplies
• Input voltage shutdown (SH)
  24 V DC (6...45 V DC), potential free
• Battery (BAT OK)
  min. 5 V DC, 1 mA; max. 30 V DC, 100 mA
• Product article number of manufacturer
  85414
• Input current
  max. 23 A
• Battery type
  Lead battery (max. 40 Ah, sealed)
• Input voltage (Uin OK)
  min. 5 V DC, 1 mA; max. 30 V DC, 100 mA
• Output voltage
  27.7...19.2 V DC
• Dimensions H×W×D
  123×65×143 mm
• Loading current
  2 A
• Temperature range
  -25...+45 °C
• Mounting method
  DIN-rail mountable TH35-7.5/TH35-15 (EN 60715)
• Input voltage
  21.6...30 V DC (buffer operation)
• Output current
  max. 20 A
• Connection
  Push-In spring clamp terminals, Mini-USB
• Sensor type
  KTY 81-210 (Art.No. 89600)
