85040 Murr Elektronik AC/DC Power Supplies

Product Details

• Weight
  500 g
• Series
  Transformators/Power Supplies
• Input current
  1.1 A (115 V AC); 0.6 A (230 V AC)
• Product article number of manufacturer
  85040
• Inrush current after 1 ms
  max. 28 A
• Frequency
  50...60 Hz
• Primary fusing external
  max. 10 A
• Parallel usage/serial usage
  no/yes (max. 2 units)
• Input voltage
  90...265 V AC/110...300 V DC
• Unit protection
  short-circuit and overload protected
• Spikes
  max. 200 mV ss/pp
• Ripple
  max. 20 mV eff/rms
• Mains failure bridging time
  min. 10 ms (115 V AC); min. 70 ms (230 V AC)
• LED display
  LED (green) for output voltage
• Output voltage
  12 V DC (SELV), ±1%; 10...15 V adjustable
• Output current
  5 A (+55 °C); 6 A (+45 °C)
• Dimensions H×W×D
  107.5×42×97.5 mm
• Relative humidity
  5...95%, no condensation
• Standards
  IEC 61010-2-201, EN 61204-3, EN 55022 B, EN 61000-3-2
• Temperature range
  0...+55 °C (storage temperature -25...+85 °C)
Efficiency
85%
Mounting method
DIN-rail mountable TH35 (EN 60715)
