85002 Murr Elektronik AC/DC Power Supplies
Part#:85002
Alt. Part#:85692
Manufacturer:Murr Elektronik
Category:AC/DC Power Supplies
Product Lifecycle:Active
Product description
85002 Murrelektronik - EVOLUTION POWER SUPPLY 3-PHASE, IN: 360-520VAC OUT: 22-28V/20ADC, Allows continuous two-phase- operation, Extra-power - for 4 seconds 50% additional power
Product Details
- Weight 2156.82 g
- Series Transformators/Power Supplies
- Inrush current after 1 ms max. 19 A
- Product article number of manufacturer 85002
- Frequency 50...60 Hz
- Primary fusing external max. 3× 20 A
- Input current 3× 1.3 A
- Input voltage 3× 324...572 V AC/480...745 V DC
- Parallel usage/serial usage max. 5 units/max. 2 units
- Unit protection short-circuit and overload protected
- Spikes max. 100 mV ss/pp
- Ripple max. 50 mV eff/rms
- Mains failure bridging time min. 19 ms (400 V AC)
- Output current 20 A (+55 °C); 15.8 A (+70 °C)
- LED display LED (green): OK; LED (red): overload
- Power Boost Iout N × 150% (min. 4 s)
- Efficiency 90% (3× 400 V AC); 89% (3× 520 V AC)
- Dimensions H×W×D 132×113×136 mm
- Output voltage 24 V DC (SELV), ±1%; 22...28 V adjustable
- Connection Screw terminals
- Mounting method DIN-rail mountable TH35 (EN 60715)
- Temperature range -25...+70 °C (storage temperature -40...+85 °C)
- Standards IEC 61010-2-201, EN 61204-3, EN 55011 A, EN 61000-3-2, SEMI F47
- Protection IP20
- Relative humidity 5...95%, no condensation
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of 85002 on Applied Automation is $502.35. Order now.
