5666100 Murr Elektronik I/O Systems

Product Details

• Weight
  270 g
• Series
  Field Bus System
• Monitoring - under voltage
  yes
• Diagnostic via BUS
  per module and channel
• Communication status
  via LED
• Monitoring - no voltage
  yes
• Short-circuit and overload
  yes
• Actuator warning
  per channel via BUS
• Sensor-system/actuator supply
  via internal system connection (max. 2× 4 A)
• Diagnostic via LED
  per module
• Product article number of manufacturer
  5666100
• I/O ports
  Open cable
• Actuator supply UA
  24 V DC (EN 61131-2), via system connection (max. 4 A)
• Sensor supply US
  24 V DC (EN 61131-2), max. 1.6 A
• Fieldbus
  via internal system connection
• Cable Length
  2.0 m
• No./diameter of wires
  10× 0.34 mm²
• Protection
  IP67
• I/O channels
  Input/Output
• LED display
  US: sensor supply and internal supply voltage (green: OK); UA: actuator supply (green: OK)
Current consumption
max. 30 mA
Material (jacket)
PVC
Input filter
1 ms
Mounting method
2-hole screw mounting
Temperature range
0...+55 °C (storage temperature -20...+75 °C)
Dimensions H×W×D
150×30×34.5 mm
Type
for 3-wire sensors or mechanical switches, PNP
Switching current per output
max. 60 mA (short-circuit and overload protected)
