56613 Murr Elektronik I/O Systems

Product Details

• Weight
  145 g
• Series
  Field Bus System
• Monitoring - under voltage
  yes
• Diagnostic via BUS
  per module and channel
• Short-circuit and overload
  yes
• Communication status
  via LED
• Monitoring - no voltage
  yes
• Diagnostic via LED
  per module and channel
• Product article number of manufacturer
  56613
• I/O ports
  M12 (female) 5-pole, A-coded
• Sensor-system/actuator supply
  via internal system connection (max. 2× 4 A)
• Mounting method
  2-hole screw mounting
• PIN 2
  Input/Diagnostic
• PIN 4
  Input
• Fieldbus
  via internal system connection
• Current consumption
  max. 50 mA
• Input filter
  1 ms
• LED display
  US: sensor supply and internal supply voltage (green: OK); UA: actuator supply (green: OK)
• Dimensions H×W×D
  151×30×34.5 mm
• Temperature range
  0...+55 °C (storage temperature -20...+75 °C)
Sensor supply US
24 V DC (EN 61131-2), max. 200 mA (M12 female), short-circuit and overload protected
Protection
IP67
Type
for 3-wire sensors or mechanical switches, PNP
