56436 Murr Elektronik I/O Systems

Product Details

• Weight
  220 g
• Series
  Field Bus System
• Monitoring - no voltage
  yes
• Product article number of manufacturer
  56436
• I/O ports
  M8, 3-pole
• Diagnostic via LED
  per module
• Fieldbus
  A-coded
• Communication status
  via LED
• Type
  for 3-wire sensors or mechanical switches, PNP
• Sensor supply US
  max. 190 mA from AS-Interface (short-circuit and overload protected)
• Dimensions H×W×D
  85×30×34.5 mm
• Mounting method
  screw fixing
• Addressing
  via master or M12 connection and programming device, presetting 1× address 31 A, 1× address 31 B
• Protection
  IP68
• Profile (IO/ID/ID2 code)
  2× S-0.A.E
• Temperature range
  -20...+60 °C (storage temperature -20...+70 °C)
• Total current
  max. 300 mA
• Address range
  1...62 (1...31 A or B)
• ASI-Power 24
  yes
• Bus voltage (AS-Interface)
  26.5...31.6 V DC
