56400 Murr Elektronik I/O Systems

Product Details

• Weight
  236 g
• Series
  Field Bus System
• Communication status
  via LED
• Diagnostic via BUS
  yes
• Diagnostic via LED
  per module
• Product article number of manufacturer
  56400
• Type
  for 3-wire sensors or mechanical switches, PNP
• Sensor supply US
  max. 200 mA from AS-Interface (short-circuit and overload protected)
• Dimensions H×W×D
  94×60×39 mm
• Protection
  IP67
• Double assignment of M12 female
  no
• Bus voltage (AS-Interface)
  26.5...31.6 V DC
• Addressing
  via built-in address port or master
• Temperature range
  -20...+60 °C (storage temperature -20...+70 °C)
• PIN 2 and PIN 4 of M12 female bridged
  yes
• Total current
  max. 250 mA
• Profile (IO/ID/ID2 code)
  S-0.A.0
• Mounting method
  DIN-rail mountable (EN 60715) or screw fixing
• Address range
  1...62 (1...31 A or B)
