55293 Murr Elektronik I/O Systems

Product Details

• Weight
  822 g
• Series
  Field Bus System
• Lamp load (8× M12 left)
  max. 1.6 A (short-circuit and overload protected)
• Monitoring - under voltage
  yes
• Mounting method
  2-hole screw mounting
• Short-circuit and overload
  yes
• Wire break upper/lower limit overload
  per channel via LED and BUS
• Monitoring - no voltage
  yes
• Actuator warning
  per channel via LED and BUS
• Input resistor (analog)
  approx. 1 MΩ, differential input
• Actuator supply UA
  24 V DC (EN 61131-2), max. 9 A
• Addressing
  Rotary switch 1...99
• Diagnostic via LED
  per module and channel
• Diagnostic via BUS
  per module and channel
• Communication status
  via LED
• Dimensions H×W×D
  42×63×225 mm
• Lamp load
  10 W
• Protection
  IP67
• I/O ports
  M12, 5-pole, A-coded
• Product article number of manufacturer
  55293
Fieldbus
PROFIBUS 12 Mbit/s; M12, B-coded
Sensor-system/actuator supply
7/8", 5-pole, 2× max. 9 A
Input range (analog)
0...10 V, (0...20 mA and 4...20 mA via adapter Art.-No. 7000-42251-0000000)
Temperature range
0...+55 °C (storage temperature -20...+70 °C)
Type
for 3-wire sensors or mechanical switches, PNP
Resolution (analog)
16 Bit
Conversion time (analog)
1 ms
Sensor supply US
24 V DC (EN 61131-2), max. 200 mA (M12 female), short-circuit and overload protected

Related documents 55293 Specs
