52015 Murr Elektronik Control Circuits
Part#:52015
Alt. Part#:6652015
Manufacturer:Murr Elektronik
Category:Control Circuits
Product Lifecycle:Active
Product description
52015 Murrelektronik - MIRO 6,2-1OUTPUT-REL.24V-1S, MIRO 6.2 24V OUTPUT RELAY, IN: 24 VAC/DC - OUT: 250 VAC/DC / 6 A, 1 N/O contact - 6,2 mm screw-type terminal
Product Details
- Weight 28 g
- Series Interface Modules
- AC-12 6 A (24/110/230 V AC)
- Switching current per output max. 6 A
- Product article number of manufacturer 52015
- AC-15 3 A (24/110/230 V AC)
- Connection voltage - current 24 V DC (19.2...30 V DC) - 17 mA
- DC-13 1 A (24 V DC); 0.2 A (110 V DC); 0.1 A (230 V DC)
- LED display LED (green)
- Power rating (voltage dependent) max. 1500 VA/120 W
- Switching frequency max. 10 Hz
- Energize/release/contact bounce time 10/15/1.5 ms
- Switching voltage max. 250 V AC/DC
- Temperature range -20...+55 °C
- Mounting method DIN-rail mountable (EN 60715)
- Min. load current 100 mA (12 V DC)
- Dimensions H×W×D 78×6.2×70 mm
- Mech./ elect. life 20 000 000 switching cycles/load dependent
- Contact material Ag Sn O2
- Test isolation voltage 4 kV; safe separation (EN 60947-1)
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of 52015 on Applied Automation is $31.15. Order now.
