51300 Murr Elektronik Control Circuits
Part#:51300
Alt. Part#:51301
Manufacturer:Murr Elektronik
Category:Control Circuits
Product Lifecycle:Active
Product description
51300 Murrelektronik - RM 122/24 OUTPUT RELAY, IN: 24 VDC - OUT: 250 VAC/DC / 5 A, 2 N/O / 2-N/C contact - 22,5 mm screw-type term.
Product Details
- Weight 124 g
- Series Interface Modules
- Product article number of manufacturer 51300
- AC-1 5 A (24/110/230 V AC)
- LED display LED (red)
- Connection voltage - current 24 V DC (21.6...28 V DC) - 29 mA
- DC-13 2 A (24 V DC); 0.4 A (110 V DC); 0.2 A (230 V DC)
- AC-15 4 A (24 V AC); 3 A (110 V AC); 2 A (230 V AC)
- Power rating (voltage dependent) max. 1000 VA/50 W
- Switching current per output max. 5 A
- Switching frequency max. 0.1 Hz (with load)
- Dimensions H×W×D 75×22.5×85 mm
- Energize/release/contact bounce time 15/15/2 ms
- Min. load current 300 mA
- Mech./ elect. life 1 000 000 switching cycles/load dependent
- Test isolation voltage 2.5 kV
- Temperature range -20...+50 °C
- Mounting method DIN-rail mountable TH35 or G32 (EN 60715)
- Contact material Ag Ni 10 hv
- Switching voltage max. 250 V AC/DC
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of 51300 on Applied Automation is $178.65. Order now.
51300 Related Documents
Manufacturer warranty
51300 Murr Elektronik
$178.65
Your price can be lower.
Log in or Create account to check your discount
This part can be ordered
Select Qty:
$178.65
$178.65 each
This item may have a lead time. To ensure availability before placing your order, chat with our team—we'll confirm for you right away!
Fast Shipping & Delivery
We deliver nationwide and international
Secure Payment Processing
Your Safety, Our Priority.
Warranty
Manufacturer warranty
Responsive Customer Support
Got Questions? We've Got Answers!
Need more details?
Feel free to chat with us
About the manufacturer
Applied Automation is an authorized Murr Elektronik distributor, offering a robust selection of high-quality components engineered to drive efficiency and innovation in industrial applications. Murr Elektronik, a leader in the electronics industry, specializes in providing sophisticated automation solutions that cater to diverse sectors by integrating cutting-edge technology with unmatched enginee...
About the Product Category
A control circuit is an essential part of electrical systems that allows for the control and management of various electrical devices. It acts as a relay point between a power source and devices, receiving input from sensors and sending instructions to control the actions of connected devices.
Recently viewed products
Relevant products
FAQ
What is the price of 51300?
Purchase the 51300 from Applied Automation at the price of $178.65. Order today.
Out if stock but available for backorder.
51300 Murrelektronik - RM 122/24 OUTPUT RELAY, IN: 24 VDC - OUT: 250 VAC/DC / 5 A, 2 N/O / 2-N/C contact - 22,5 mm screw-type term.
