27025 Murr Elektronik I/O Distributors

Product Details

• Weight
  511 g
• Series
  Distribution Systems
• Product article number of manufacturer
  27025
• PIN 5
  (Earth)
• PIN 4
  (NO)/(S1)
• PIN 3
  (-)
• Bend radius (moving)
  10× outer Ø
• Travel speed (C-track)
  max. 2 m/s
• No. of bending cycles (C-track)
  max. 2 Mio. (25 °C)
• PIN 2
  (NC)/(S2)
• Acceleration (C-track)
  max. 10 m/s²
• Current load capacity
  to DIN VDE 0298-4
• Bend radius (fixed)
  5× outer Ø
• PIN 1
  (+)
• Temperature range (mobile)
  -5...+70 °C
• Test voltage
  2000 V AC
• chemical resistance
  good resistance to oil, gasoline and chemicals (EN 60811-404)
• Temperature range (fixed)
  -30...+80 °C
• Shore hardness (jacket)
  87 ±5 A
• Color (jacket)
  gray
Nominal voltage
U0/U 300/300 V AC
Outer-Ø (jacket)
8.1 mm ±5%
Material (jacket)
PUR/PVC
Jacket Color
gray
Wire-Ø incl. isolation
1.3 mm ±5% (0.34 mm²); 1.8 mm ±5% (0.75 mm²)
Shield
no
Shore hardness (wire isolation)
43 ±5 D
Material property (wire isolation)
CFC-, cadmium-, silicone- and lead-free
AWG
similar to AWG 22 (0.34 mm²); similar to AWG 18 (0.75 mm²)
Resistor (core)
max. 57 Ω/km (0.34 mm²), max. 26 Ω/km (0.75 mm²); (20 °C)
Single wire Ø (core)
0.15 mm (0.34 mm²); 0.2 mm (0.75 mm²)
Material (wire isolation)
PVC
Color/numbering of wires
wh, ye, gr, grpk, rdbl, gn, whgn, brgn+bl, br, gnye longitudinally striped
Diameter (core)
8× 0.34 + 3× 0.75 mm²
Construction (core)
19× 0.15 mm (0.34 mm²); 24× 0.2 mm (0.75 mm²); (multi-strand wire class 5)
Material (wire)
Cu wire, bare
Approval (cable)
UL (AWM-Style 21441/10955), CE conform
Cable weight [g/m]
115,5 g
Cable Type
2 (PUR/PVC)
Cable number
363
Cable identification
363
Outer Ø
8.1 mm ±5%
Wire isolation
PVC
C-track properties
2 Mio.
No./diameter of wires
8× 0.34 + 3× 0.75 mm²
Dimensions H×W×D
100×50.2×17 mm
Operating voltage
24 V DC ±25%
Total current
max. 8 A
Protection
IP65 and IP67 when plugged and screwed down (EN 60529)
Signal per port
2
Temperature range
-20...+80 °C
Housing
Plastic, flame retardant
Material
PBT
Locking of ports
Screw thread (M12×1 mm)
Operating current per contact
max. 4 A
